The ebittFormaFree application designs and calculates a form with columns, slabs and beams. all reactions are provided, slabs, beams and the loads on the pillars.

In the Free version of the app solves a project with 400 x 400 cm. In Full version you can change the value of the total size of the project.

Now you can add more columns. To do this simply select the beam and use the + P option. After you can edit the Pilar.

You can also back the changes and move forward as any editor. This is done on the main screen with the [1AA +] keys to advance and [Zz-] to return.


Interface

The ebittForma application has an interactive interface that allows data entry and the fashion design graphically.

The main screen shows the shape design with the names of the slabs, the beams with its dimensions and slabs. The transition to the other screens is made using icons for each operation.

On the main screen you can make zoon and move the way allowing the selection of elements for data change.

The other screens are:

- Screen for division of slabs;
- Screen to change the data of the slabs, beams and columns;
- Information display of the reactions in slabs, beams and loads on pillars;
- Screen to erase beams that were formed by divisions of the slabs;
- Screen to show the horizontal cut in the structure;
- Screen to show the vertical cut in the structure.


Other options:

- [+] [-] To zoom in the main screen;
- [1AA +] on the main screen advances at issue;
- [Zz-] on the main screen back on the issue;
- [Clear] to clear during editing of data and to restart new way just press three times on the main screen;
- [Enter] [Enter] to make the transition between screens. The transition can also be made in the machine's return key;
- [1AA] to change the type of numeral on the issue of the names of the elements;
- [1AA +] to reposition the cut in the project on the screen of the cuts;
- [Zz-] to reposition the cut in the project on the screen of the cuts.

The application starts with a form with 4 pillars, 4 beams and slab 1 with size 400 x 400 cm. In Free version can not change this dimension of the total project.

From the Main Menu of your device option exists:
- Recording of the screens as a figure in the gallery;
- Project data recording;
- Project data recovery;
The data file is saved and retrieved the memory card always with the same name. To archive different designs simply copy the file to another folder or location.

Comments:
- There is no guarantee on the results;
- No in-app ads.
