알칸도 밸런싱로봇 조이스틱 리모컨 (RCanDo Joystick Remocon B) on Windows Pc

Developed By: RCanDo

License: Free

Rating: 5,0/5 - 1 votes

Last Updated: December 26, 2023

Download on Windows PC

Compatible with Windows 10/11 PC & Laptop

App Details

Version 1.0
Size 2.6 MB
Release Date July 20, 18
Category Education Apps

App Permissions:
Allows applications to connect to paired bluetooth devices. [see more (7)]

What's New:
블루투스 리모컨 앱을 릴리즈합니다. [see more]

Description from Developer:
"Alkane also balancing robot with a remote control that can control with wireless Bluetooth communication joysticks, buttons, controlled by voice recognition. You can modify,... [read more]

App preview ([see all 5 screenshots]  /  [view video])

App preview

About this app

On this page you can download 알칸도 밸런싱로봇 조이스틱 리모컨 (RCanDo Joystick Remocon B) and install on Windows PC. 알칸도 밸런싱로봇 조이스틱 리모컨 (RCanDo Joystick Remocon B) is free Education app, developed by RCanDo. Latest version of 알칸도 밸런싱로봇 조이스틱 리모컨 (RCanDo Joystick Remocon B) is 1.0, was released on 2018-07-20 (updated on 2023-12-26). Estimated number of the downloads is more than 10. Overall rating of 알칸도 밸런싱로봇 조이스틱 리모컨 (RCanDo Joystick Remocon B) is 5,0. Generally most of the top apps on Android Store have rating of 4+. This app had been rated by 1 users, 1 users had rated it 5*, 1 users had rated it 1*.

How to install 알칸도 밸런싱로봇 조이스틱 리모컨 (RCanDo Joystick Remocon B) on Windows?

Instruction on how to install 알칸도 밸런싱로봇 조이스틱 리모컨 (RCanDo Joystick Remocon B) on Windows 10 Windows 11 PC & Laptop

In this post, I am going to show you how to install 알칸도 밸런싱로봇 조이스틱 리모컨 (RCanDo Joystick Remocon B) on Windows PC by using Android App Player such as BlueStacks, LDPlayer, Nox, KOPlayer, ...

Before you start, you will need to download the APK/XAPK installer file, you can find download button on top of this page. Save it to easy-to-find location.

[Note] You can also download older versions of this app on bottom of this page.

Below you will find a detailed step-by-step guide, but I want to give you a fast overview of how it works. All you need is an emulator that will emulate an Android device on your Windows PC and then you can install applications and use it - you see you're playing it on Android, but this runs not on a smartphone or tablet, it runs on a PC.

If this doesn't work on your PC, or you cannot install, comment here and we will help you!

Step By Step Guide To Install 알칸도 밸런싱로봇 조이스틱 리모컨 (RCanDo Joystick Remocon B) using BlueStacks

  1. Download and Install BlueStacks at: https://www.bluestacks.com. The installation procedure is quite simple. After successful installation, open the Bluestacks emulator. It may take some time to load the Bluestacks app initially. Once it is opened, you should be able to see the Home screen of Bluestacks.
  2. Open the APK/XAPK file: Double-click the APK/XAPK file to launch BlueStacks and install the application. If your APK/XAPK file doesn't automatically open BlueStacks, right-click on it and select Open with... Browse to the BlueStacks. You can also drag-and-drop the APK/XAPK file onto the BlueStacks home screen
  3. Once installed, click "알칸도 밸런싱로봇 조이스틱 리모컨 (RCanDo Joystick Remocon B)" icon on the home screen to start using, it'll work like a charm :D

[Note 1] For better performance and compatibility, choose BlueStacks 5 Nougat 64-bit read more

[Note 2] about Bluetooth: At the moment, support for Bluetooth is not available on BlueStacks. Hence, apps that require control of Bluetooth may not work on BlueStacks.

How to install 알칸도 밸런싱로봇 조이스틱 리모컨 (RCanDo Joystick Remocon B) on Windows PC using NoxPlayer

  1. Download & Install NoxPlayer at: https://www.bignox.com. The installation is easy to carry out.
  2. Drag the APK/XAPK file to the NoxPlayer interface and drop it to install
  3. The installation process will take place quickly. After successful installation, you can find "알칸도 밸런싱로봇 조이스틱 리모컨 (RCanDo Joystick Remocon B)" on the home screen of NoxPlayer, just click to open it.

Discussion

(*) is required

"Alkane also balancing robot with a remote control that can control with wireless Bluetooth communication joysticks, buttons, controlled by voice recognition. You can modify, such as PID gain balancing robot with a remote control.
Bluetooth module uses the 'HC-06'.
It is also available for other Mobile Robot using Bluetooth module does not have to be "even alkanes balancing robot.

Data transmitted through the Bluetooth communication;
1. joystick x, y values ​​(range: -100 to 100):
     For '(78, -34): x78y-34
2. Voice Command Data:
     "Forward" (or "front"): f
     "Back" (or "back"): b
     "To the left" (or "left"): l
     "To the right" (or "Right"): r
     "Stop" (or "stop", "stop", "stop"): s
3. 'autonomous' button: a
4. 'Manual' button: x0y0

Skew, PID gain, time constant change data;
Corrected value of each button in front and the changed value by pressing the transmit button.
1. (initial slope of the balancing robot) Tilt: t (number)
2. The proportionality (proportional gain): p (number)
3. integration (integral term gain): i (number)
4. Derivative (derivative term gain): d (number)
5. time (time constant): k (number)
6. The storage (storage balancing the current state value to the EEPROM of the robot): e

[Bluetooth pairing operation after installing the app;
1. The power to the Bluetooth module (HC-06), type (LED is blinking state)
2. Run, go to the Bluetooth settings on your smartphone
3. 'HC-06' selected from the dial device
4. Registration and enter the password "1234" device
5. haejumyeon the pairing operation once the initial search

[How to Launch App;
1. Click on the icon to run the app
2. 'Connect' button
3. 'HC-06' was selected for the pairing operation
4. When changing the Bluetooth connection status LED is blinking that was turned on
5. Drag the joystick Joystick-value transfer
6. That is, press the "Voice instruction" button, a voice command value ( 'f', 'b', 'l', 'r', 's') transmission
7. Press the "autonomous" button autonomous command value ( 'a') transmission
8. If manual operation is possible enjoy the 'Manual' button
9. gradient, to change the PID gain, time constant click input window to edit and click
10. Save @EEPROM "one button OFF the current state of the PID when such gain is stored to start the search with the modified value back to the robot balancing operation (balancing robot without pressing the Save button in the balancing robot then on again search operation to a previous PID gain)
11. The data received can be sure of the Arduino serial monitor, etc. Connect the Bluetooth module
12. Exit the app is 'old' button of your smartphone, click

Thank you.
